Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry

  • Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry
  • Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry
  • Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry
  • Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry
  • Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry
  • Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry
Place of Origin Beijing, China
Brand Name BGT
Model Number WS-601ABS5
Minimum Order Quantity 1 piece
Price $50.80/pieces 1-9 pieces
Packaging Details Carton

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name 0.5 Mm Resolution Tipping Bucket Rain Gauge For Water Water Industry Resolution 0.5mm
Model Tipping Bucket Rain Guage Inner Diameter 200mm(8 Inch) ±0.3%
Measuring Range ≤4mm/min Accuracy ±≤ 6%
Operating Temperature -10℃~50℃ Material ABS& PC
Weight 1.6kg Packing Size 30*30*42cm
Leave a Message
Product Description
Please Attention
Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry 0

Beijing Guoxinhuayuan Technology Co.,Ltd OFFER YOU:

1.Factory direct price.
2.Nice quality.
3.Small order is welcome.
4.Online payment.
5.Refund money in case of bad quality.
6.Sample offered but you need to pay it.
7.1 year free repair for quality warranty.
Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry 1

0.5 mm resolution electronic tipping bucket rain gauge for water Water industry

The Model WS-601ABS2 tipping bucket rain Gauge was designed for the National Weather Service to provide a reliabl, low-cost tipping bucket rain sensor. It has been update and improved with the additionof an inner funnel to even the flow of the railfall into the gauge, providing better accuracy at higher rainfall rates. It simplicity of esign assures trouble-free opertaion , yet provide accurate rainfall measurement . And this kind of rain gauge also can provide you the data logger feature and temperature.

Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry 2
Inner diameter
200mm/8inch   ±0.3%
Resolution
0.5 mm
Measuring range
4mm/min
Accuracy
±≤ 2%(≤ 0.4mm/min); ±≤ 4% (≤4mm/min);
Material
ABS+PC
Insect protection
Stainless steel Mesh
Operating Temperature
-10℃~50℃
Discharge Control
Straight through flow mechanism
Level Control
Bull-eye level fitted on base
Mounting holes
Three mountings
Weight
2.1 kg
Working humidity
0%-95%RH
Packing size
270*270*430(MM)
Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry 3
Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry 4



Application
Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry 6
Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry 8
Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry 10
Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry 12
Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry 14
Company Profile

   Beijing Guoxinhuayuan Technology Co.,Ltd is a Hi-tech company with R&D, production, marketing, project implementation and after sales. We are focus on providing professional hydrology and meteorology monitoring device and technical service, and developed a series of flood early warning system products by ourselves, which owing more than 50 patents and 60 software copyrights. Then our product line is including monitoring products, communication products, early warning products and cloud platform. However, our products have been sold to more than 30 countries, such as Australia, Japan, Sri Lanka and so on. Especially our tipping bucket rain gauge is doing well in foreign countries. Meanwhile, our products are covered all provinces in China and we have Guangxi/Guangdong/Hunan/Hubei/Qinhai branches.

     We are devoted to solving the flood disaster problems for human beings and becoming one of the famous brands in the flood early-warning industry. Welcome to contact us.
Plastic weighing type tipping bucket 0.2mm rain gauge hotting
Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry 16
Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry 18
Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry 20
Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry 22
EXS&CES
Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry 23
Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry 25
Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry 27
Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry 29
Accurate and 0.5mm Resolution Electronic Tipping Bucket Rain Gauge for Water Industry 31
Advantages& FAQ

Why Choose Us


    ◆8 years in hydrology and meteorology wireless communication industry
  ◆Apply in more than 50 countries & areas
  ◆Certificated completed
  ◆Millions of terminals on-line
  ◆Strong R&D team, senior staff more than 60
  ◆Support OEM/ODM cooperation

FAQ


Q1. Can I have a sample order ?
Plastic weighing type tipping bucket 0.2mm rain gauge hotting
A: Yes, we welcome sample order to test and check quality.Mixed samples are acceptable.

Q2. What about the lead time?

A:Sample needs 3-5 days, mass production time needs 1-2 weeks.
Plastic weighing type tipping bucket 0.2mm rain gauge hotting
Q3. Do you have any MOQ limit?

A: Low MOQ, 1pc for sample checking is available.

Q4. How do you ship the goods and how long does it take to arrive?

A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5. How to proceed an order ?

A: Firstly let us know your requirements or application.Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order.Fourthly We arrange the production.

Q6. Is it OK to print my logo on the products?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7: Do you offer guarantee for the products?

A: Yes, we offer 2-5 years warranty to our products.

Q8: How to deal with the faulty?
Plastic weighing type tipping bucket 0.2mm rain gauge hotting
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.Secondly, during the guarantee period, we will send new one with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
